Item no. Part number Designation/description Quant information
1 A 123 250 01 02  CONVERTER

Replaced by: A 722 250 16 02 		-
1 A 722 250 16 02  CONVERTER 270 MM 001
5 N 007603 010100  SEAL RING 001
6 N 000908 010004  SCREW PLUG

Replaced by: N 000000 000648 		-
6 N 000000 000648  SCREW PLUG 001
----- A 123 257 00 40  BRACKET/PART NAME MISSING
CONVERTER HOUSING
NOT FOR U.S.A. 		001
10 N 000933 008325  SCREW
TRANSMISSION TO ENGINE 		006
11 N 000137 008204  SPRING WASHER
TRANSMISSION TO ENGINE 		006
12 A 110 990 20 40  WASHER
TRANSMISSION TO ENGINE 		006
20 A 130 250 11 05  HOUSING

Replaced by: A 115 250 77 05
• A 115 270 19 96 [1 pcs.] 		-
20 A 115 250 58 05  HOUSING

Replaced by: A 115 250 77 05
• A 115 270 19 96 [1 pcs.]

[074]
UP TO TRANSMISSION:
107 005102
108 015328
110 002961, ON 115 270 16 01, U.S.A.
110 001010, ON 115 270 19 01, CALIFORNIA
 -
20 A 115 250 77 05  HOUSING

[073]
FROM TRANSMISSION:102 002735 WITH 114 270 29 01
[076]
FROM TRANSMISSION:
107 005103
108 015329
110 002962, ON 115 270 16 01, U.S.A.
110 001011, ON 115 270 19 01, CALIFORNIA
[219]
UP TO TRANSMISSION 119 000678 WITH 123 270 09 01
 001
----- A 115 250 03 57  BREATHER

Replaced by: A 115 250 00 66
• A 115 257 04 83 [1 pcs.] 		-
----- A 115 250 00 66  OIL PIPE
WITH RUBBER CAP;REPAIR SIZE

[055]
UP TO TRANSMISSION
107 002482
108 005428
 001
26 A 115 250 05 57  BREATHER

[057]
FROM TRANSMISSION
107 002483
108 005429
[219]
UP TO TRANSMISSION 119 000678 WITH 123 270 09 01
 001
27 A 115 257 00 80  GASKET -
28 A 115 257 10 57  SCREW COLLAR 001
32 N 000908 022010  SCREW PLUG 002
----- A 100 277 07 14  INTERMEDIATE PLATE/PART NAME MISSING
SEE FIG. NO.: 445 446 		-
----- A 123 270 06 01  AUTOMATIC TRANSMISSION 001
50 A 116 270 00 90  HOUSING
WITH PRIMARY PUMP 		001
51 A 100 277 17 50  BUSHING 001
51 A 116 277 03 50  BUSHING 001
52 A 004 997 05 47  SEAL RING 001
53 A 100 277 18 50  BUSHING 001
53 A 116 277 02 50  BUSHING 001
54 A 004 997 05 48  SEAL RING 001
----- A 100 277 07 14  INTERMEDIATE PLATE

[002]
NO LONGER AVAILABLE INDIVIDUALLY
 -
55 N 000931 008046  SCREW

Replaced by: N 304017 008018 		-
55 N 304017 008018  SCREW 004
56 N 000137 008204  SPRING WASHER 004
59 N 000625 016008  GROOVED BALL BEARING 001
60 A 115 270 21 50  BUSHING 001
61 A 115 272 06 55  SEAL RING

Replaced by: A 316 272 04 55 		-
61 A 316 272 04 55  SEAL RING 004
62 A 115 272 07 92  BOOT/PART NAME MISSING
SEE FIG. NO.: 152 		001
65 A 115 270 78 20  FLANGE

Replaced by: A 115 270 95 20
• A 115 270 73 32 [1 pcs.]

[231]
UP TO TRANSMISSION
112 005086, ON 123 270 11 01
117 003750, ON 123 270 12 01
118 016722
119 000778, ON 123 270 17 01
 -
65 A 115 270 95 20  FLANGE

[233]
FROM TRANSMISSION:
112 005087, ON 123 270 11 01
117 003751, ON 123 270 12 01
118 016723
119 000779, ON 123 270 17 01
[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
 001
----- N 005401 303000  BALL

[002]
NO LONGER AVAILABLE INDIVIDUALLY
 -
67 A 115 272 12 92  BOOT 001
68 A 115 272 14 92  BOOT 001
70 A 115 272 02 31  PISTON

[231]
UP TO TRANSMISSION
112 005086, ON 123 270 11 01
117 003750, ON 123 270 12 01
118 016722
119 000778, ON 123 270 17 01
 001
71 A 115 993 52 01  SPRING 028
72 A 115 270 04 41  BRACKET 001
73 A 115 994 08 35  SNAP RING 001
74 A 000 994 14 40  SNAP RING 001
75 A 006 981 42 10  NEEDLE BEARING 001
75 A 004 981 70 10  NEEDLE BEARING 001
80 A 112 272 03 25  INNER DISC 2.1 MM 003
81 A 109 272 19 26  OUTER DISC 5.0 MM 001
87 A 109 272 23 26  OUTER DISC
AS REQUIRED 5.0 MM 		003
87 A 109 272 22 26  OUTER DISC
AS REQUIRED 4.5 MM 		003
88 A 112 272 01 73  LOCK 156 MM

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
100 A 115 270 61 43  PLANETARY CARRIER 001
----- A 115 272 14 07  SUN GEAR

[002]
NO LONGER AVAILABLE INDIVIDUALLY
[402]
NO LONGER AVAILABLE
 -
----- A 115 272 10 08  ANNULUS

[002]
NO LONGER AVAILABLE INDIVIDUALLY
[402]
NO LONGER AVAILABLE
 -
105 A 004 981 21 10  NEEDLE BEARING

Replaced by: A 000 981 14 11 		-
105 A 000 981 14 11  NEEDLE BEARING 001
106 A 115 272 33 62  GUARD PLATE 001
107 A 115 272 02 73  LOCK 130 MM 001
108 A 112 994 07 35  SNAP RING 125 MM 001
109 A 115 272 34 62  GUARD PLATE 001
110 A 115 271 17 52  SPACER WASHER
AS REQUIRED 0.1 MM 		001
110 A 115 271 18 52  SPACER WASHER
AS REQUIRED 0.2 MM 		001
110 A 115 271 19 52  SPACER WASHER
AS REQUIRED 0.5 MM 		001
111 A 115 271 21 52  SPACER WASHER
AS REQUIRED 0.1 MM 		001
111 A 115 271 22 52  SPACER WASHER
AS REQUIRED 0.2 MM 		001
111 A 115 271 23 52  SPACER WASHER
AS REQUIRED 0.5 MM 		001
120 A 115 270 58 43  PLANETARY CARRIER 001
----- A 115 270 60 25  DRIVE SHAFT

[002]
NO LONGER AVAILABLE INDIVIDUALLY
 -
----- A 109 272 00 08  ANNULUS/PART NAME MISSING
NOT FOR U.S.A. 		-
127 A 115 272 04 73  LOCK 156 MM 001
SEE FIG. NO.: 183 E
PART NAME MISSING
130 A 109 272 18 45  FLANGE 001
132 A 115 272 22 31  PISTON

[135]
UP TO TRANSMISSION:
107 009932
108 029328
109 020131
110 004881, ON 115 270 16 01, U.S.A.
110 UNTIL PRODUCTION STOP, ON 115 270 19 01, CALIFORNIA
 001
132 A 115 272 24 31  PISTON

[137]
FROM TRANSMISSION
107 009933
108 029329
109 020132
110 004882, ON 115 270 16 01
 001
134 A 109 272 03 92  BOOT 001
134 A 115 272 13 92  BOOT 001
134 A 115 272 16 92  BOOT 001
136 A 109 272 10 92  BOOT 001
138 A 115 272 54 24  DISC SUPPORT

[135]
UP TO TRANSMISSION:
107 009932
108 029328
109 020131
110 004881, ON 115 270 16 01, U.S.A.
110 UNTIL PRODUCTION STOP, ON 115 270 19 01, CALIFORNIA
 001
138 A 115 272 44 24  DISC SUPPORT

[137]
FROM TRANSMISSION
107 009933
108 029329
109 020132
110 004882, ON 115 270 16 01
 001
139 A 115 272 04 73  LOCK 156 MM 001
140 A 115 272 00 25  INNER DISC
AS REQUIRED 2.1 MM

[135]
UP TO TRANSMISSION:
107 009932
108 029328
109 020131
110 004881, ON 115 270 16 01, U.S.A.
110 UNTIL PRODUCTION STOP, ON 115 270 19 01, CALIFORNIA
 003
140 A 123 272 00 25  INNER DISC 2.1 MM

[137]
FROM TRANSMISSION
107 009933
108 029329
109 020132
110 004882, ON 115 270 16 01
 003
145 A 109 272 23 26  OUTER DISC
AS REQUIRED 5.0 MM 		002
148 A 109 272 22 26  OUTER DISC
AS REQUIRED 4.5 MM 		002
149 A 109 272 06 26  OUTER DISC 3.0 MM

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
150 A 109 272 21 26  OUTER DISC
AS REQUIRED 5.0 MM

[135]
UP TO TRANSMISSION:
107 009932
108 029328
109 020131
110 004881, ON 115 270 16 01, U.S.A.
110 UNTIL PRODUCTION STOP, ON 115 270 19 01, CALIFORNIA
 001
150 A 115 270 00 38  DISC

[137]
FROM TRANSMISSION
107 009933
108 029329
109 020132
110 004882, ON 115 270 16 01
 001
151 A 112 272 01 73  LOCK 156 MM

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
152 A 115 993 41 03  SPRING

[135]
UP TO TRANSMISSION:
107 009932
108 029328
109 020131
110 004881, ON 115 270 16 01, U.S.A.
110 UNTIL PRODUCTION STOP, ON 115 270 19 01, CALIFORNIA
 020
152 A 115 993 43 03  SPRING

[137]
FROM TRANSMISSION
107 009933
108 029329
109 020132
110 004882, ON 115 270 16 01
[385]
UP TO TRANSMISSION:
117 030915
118 086932
120 014920
 020
153 A 116 272 00 67  RING

[135]
UP TO TRANSMISSION:
107 009932
108 029328
109 020131
110 004881, ON 115 270 16 01, U.S.A.
110 UNTIL PRODUCTION STOP, ON 115 270 19 01, CALIFORNIA
 001
153 A 109 272 02 67  RING

[137]
FROM TRANSMISSION
107 009933
108 029329
109 020132
110 004882, ON 115 270 16 01
 001
156 A 002 981 31 10  NEEDLE BEARING 001
160 A 115 270 56 25  DRIVE SHAFT

[135]
UP TO TRANSMISSION:
107 009932
108 029328
109 020131
110 004881, ON 115 270 16 01, U.S.A.
110 UNTIL PRODUCTION STOP, ON 115 270 19 01, CALIFORNIA
 001
160 A 115 270 61 25  DRIVE SHAFT

[137]
FROM TRANSMISSION
107 009933
108 029329
109 020132
110 004882, ON 115 270 16 01
 001
161 A 002 981 32 10  NEEDLE BEARING 001
162 A 115 272 34 62  GUARD PLATE 001
163 A 002 994 26 41  LOCK 001
164 A 002 981 30 10  NEEDLE BEARING 001
165 A 115 272 02 73  LOCK 130 MM 001
166 A 112 994 07 35  SNAP RING 125 MM 001
167 A 005 981 81 10  NEEDLE BEARING 001
172 A 115 270 55 25  DRIVE SHAFT 001
178 A 115 270 47 43  PLANETARY CARRIER 001
----- A 109 272 00 08  ANNULUS

[002]
NO LONGER AVAILABLE INDIVIDUALLY
 -
179 A 007 981 39 10  NEEDLE BEARING 001
180 A 004 981 40 10  NEEDLE BEARING 001
181 A 115 272 37 62  GUARD PLATE 001
182 A 001 981 18 25  BALL BEARING 001
183 A 115 272 49 62  GUARD PLATE 001
185 A 100 272 04 55  SEAL RING
DRIVE SHAFT 		001
187 A 115 272 45 62  GUARD PLATE 001
190 A 115 272 24 45  FLANGE 001
191 N 007987 006130  SCREW 003
192 A 115 271 13 52  SPACER WASHER
AS REQUIRED 0.1 MM 		001
192 A 115 271 14 52  SPACER WASHER
AS REQUIRED 0.2 MM 		001
192 A 115 271 15 52  SPACER WASHER
AS REQUIRED 0.3 MM 		001
----- A 000 304 08 90  SOLENOID
KICK-DOWN SOLENOID VALVE ELEKTROTEILE

[466]
NO LONGER AVAILABLE;ORDER INDIVIDUAL PARTS
 -
----- A 000 304 16 90  SOLENOID
KICK-DOWN SOLENOID VALVE BINDER

[466]
NO LONGER AVAILABLE;ORDER INDIVIDUAL PARTS
 -
193 A 000 304 11 90  SOLENOID
(MAGNET COIL) TO 000 304 08 90 		001
193 A 000 304 25 90  SOLENOID
(MAGNET COIL) TO 000 304 16 90 		001
198 A 000 304 12 90  SOLENOID
(MAGNET FRAME) TO 000 304 08 90 		001
198 A 000 304 24 90  SOLENOID
(MAGNET FRAME) TO 000 304 16 90 		001
199 A 008 997 30 48  SEAL RING 001
200 A 010 997 77 45  SEAL RING 001
201 A 001 997 35 48  SEAL RING 001
202 A 115 304 01 60  SEAL RING 001
210 A 115 270 76 11  TRANSMISSION CASE

[092]
UP TO TRANSMISSION:109 001423
[219]
UP TO TRANSMISSION 119 000678 WITH 123 270 09 01
[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
 001
213 A 115 997 06 30  SCREW PLUG 001
214 N 007603 008105  SEAL RING 001
215 A 006 997 61 46  SEAL RING 001
220 A 115 272 11 92  BOOT/PART NAME MISSING
NOT FOR U.S.A. 		001
223 A 115 270 08 68  GUIDE TUBE

[016]
AGAINST SQUEALING OF TRANSMISSION
 001
226 A 115 277 15 40  BRACKET
TOP 		001
----- A 115 270 80 07  VALVE BODY ASSEMBLY
MODULATOR VALVE 		001
229 A 115 993 20 10  SPRING 002
230 N 000931 006115  SCREW

Replaced by: N 000933 006151 		-
230 N 000933 006151  SCREW 002
----- N 000912 006063  SCREW

Replaced by: N 000912 006170 		-
----- N 000912 006170  SCREW 001
231 N 000137 006204  SPRING WASHER 003
233 A 109 271 00 80  GASKET

Replaced by: A 109 271 01 80 		-
233 A 109 271 01 80  GASKET 001
233 A 115 271 14 80  GASKET

Replaced by: A 115 271 17 80 		-
233 A 115 271 17 80  GASKET/PART NAME MISSING
NOT FOR U.S.A. 		001
236 A 000 545 42 06  SWITCH
STARTER NON-REPEAT AND BACK-UP LIGHT SWITCH 		001
236 A 000 545 46 06  SWITCH/PART NAME MISSING
STARTER NON-REPEAT AND BACK-UP LIGHT SWITCH
NOT FOR U.S.A. 		001
239 N 000137 005203  SPRING WASHER 002
241 N 000933 005081  SCREW/PART NAME MISSING
NOT FOR U.S.A. 		002
243 A 115 278 25 20  LEVER 001
248 A 115 545 01 42  FOLLOWER 001
----- N 000084 004174  SCREW 001
----- N 000137 004202  SPRING WASHER 001
250 A 115 278 16 10  CONTROL SHAFT/PART NAME MISSING
NOT FOR U.S.A. 		001
----- N 000931 006095  SCREW
RANGE SELECTOR LEVER TO SHAFT 		001
----- N 000137 006205  SPRING WASHER
RANGE SELECTOR LEVER TO SHAFT 		001
----- N 000934 006013  NUT

Replaced by: N 304032 006008 		-
----- N 304032 006008  NUT/PART NAME MISSING
RANGE SELECTOR LEVER TO SHAFT
NOT FOR U.S.A. 		001
270 A 115 270 04 57  DETENT 001
273 N 006912 006006  SCREW 001
274 N 000137 006204  SPRING WASHER 001
280 A 116 270 03 89  VALVE 001
285 A 109 270 11 89  VALVE 001
288 A 126 277 11 58  SEAL HOLDER

Replaced by: A 140 277 01 51

[414]
THE OLD PART MUST NO LONGER BE INSTALLED
 -
288 A 140 277 01 51  SPACER RING 002
290 A 010 997 08 45  SEAL RING

Replaced by: A 016 997 34 48 		-
290 A 016 997 34 48  O-RING 002
291 A 115 993 00 22  SPRING 001
292 A 109 277 02 75  PIN
AS REQUIRED 23 MM 		002
292 A 109 277 03 75  PIN
AS REQUIRED 24 MM 		002
292 A 109 277 04 75  PIN
AS REQUIRED 25 MM 		002
292 A 109 277 05 75  PIN
AS REQUIRED 26 MM 		002
295 A 115 277 02 74  PIN 001
296 A 115 277 04 24  LEVER 001
299 A 115 277 53 75  PIN 002
300 A 115 993 02 25  SPRING 001
301 A 115 277 17 71  SCREW 001
302 A 115 990 04 51  NUT 001
316 A 115 270 61 32  PISTON 88 MM 001
321 A 115 272 08 92  BOOT 001
----- A 115 993 09 02  SPRING -
----- A 115 277 48 75  PIN -
324 A 115 994 17 35  SNAP RING 001
325 A 115 993 18 05  SPRING 001
330 A 115 277 37 03  COVER 001
335 A 008 997 35 45  SEAL RING 001
336 A 115 994 30 35  SNAP RING 001
337 A 115 270 24 89  VALVE 001
338 A 002 997 21 48  SEAL RING 001
339 N 007603 016103  SEAL RING 001
344 A 115 270 14 59  LEVER

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
----- A 007 997 44 47  SEAL RING

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
348 A 115 990 17 40  WASHER

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
349 N 006799 009002  LOCK PLATE

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
355 A 115 270 08 59  LEVER

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
356 N 000933 006123  SCREW

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
357 N 000137 006204  SPRING WASHER

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
358 N 000934 006013  NUT

Replaced by: N 304032 006008 		-
358 N 304032 006008  NUT

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
360 A 116 270 03 62  BRAKE BAND

Replaced by: A 116 270 17 62 		-
360 A 116 270 17 62  BRAKE BAND
REVERSE SPEED 		001
363 A 115 993 54 03  SPRING 001
364 A 115 993 55 03  SPRING 001
366 A 115 270 59 32  PISTON 62 MM 001
370 A 115 272 03 92  BOOT 001
398 A 115 277 19 03  COVER/PART NAME MISSING
NOT FOR U.S.A. 		001
400 A 010 997 59 45  SEAL RING 001
402 A 115 994 14 35  SNAP RING 001
425 A 115 270 71 32  PISTON 88 MM

[697]
PART IS ONLY OR ALSO SUPPLIED AS RECONDITIONED PART
 001
428 A 115 277 02 55  SEAL RING 001
----- A 115 993 22 05  SPRING

Replaced by: A 115 993 23 05
• A 115 277 16 77 [1 pcs.]

[140]
UP TO TRANSMISSION:
102 013681, ON 114 270 29 01
107 009802
108 028378
109 019781
110 004581, ON 115 270 16 01, U.S.A.
110 001500, ON 115 270 19 01, CALIFORNIA
112 000537
117,118,119 000020
 -
430 A 115 993 23 05  SPRING

[144]
FROM TRANSMISSION:
102 013682, ON 114 270 29 01
107 009803
108 028379
109 019782
110 004582, ON 115 270 16 01, U.S.A.
110 001501, ON 115 270 19 01, CALIFORNIA
112 000538
117,118,119 000021
 001
431 A 115 277 16 77  GUIDE

[144]
FROM TRANSMISSION:
102 013682, ON 114 270 29 01
107 009803
108 028379
109 019782
110 004582, ON 115 270 16 01, U.S.A.
110 001501, ON 115 270 19 01, CALIFORNIA
112 000538
117,118,119 000021
 001
432 A 115 277 37 03  COVER 001
433 A 115 994 30 35  SNAP RING 001
434 A 008 997 35 45  SEAL RING 001
436 A 115 270 59 62  BRAKE BAND

Replaced by: A 115 270 73 62 		-
436 A 115 270 73 62  BRAKE BAND B 2 001
440 A 115 270 63 62  BRAKE BAND

Replaced by: A 115 270 71 62 		-
440 A 115 270 71 62  BRAKE BAND B 1 001
445 N 000137 008204  SPRING WASHER 011
446 N 000931 008244  SCREW 011
448 A 115 277 26 80  GASKET

Replaced by: A 115 277 33 80 		-
448 A 115 277 33 80  GASKET

[092]
UP TO TRANSMISSION:109 001423
[219]
UP TO TRANSMISSION 119 000678 WITH 123 270 09 01
 001
452 A 115 272 01 17  GEAR

Replaced by: A 722 272 00 17 		-
452 A 722 272 00 17  GEAR 001
455 A 115 278 07 74  PIN 001
456 A 000 994 42 41  LOCK 001
457 A 115 278 02 21  PAWL 001
458 A 115 993 02 22  SPRING 001
460 A 115 270 10 65  LINKAGE

Replaced by: A 115 270 06 65
• A 115 278 05 17 [1 pcs.]
• A 115 990 21 40 [1 pcs.]

[368]
UP TO TRANSMISSION:
112 118876, ON 123 270 29 01
117 031960
118 091348
119 002628, ON 123 270 17 01
120 017270
[415]
THIS NOTE OF REPLACEMENT APPLIES ONLY TO THE ITEM LISTED OPPOSITE
 -
460 A 115 270 06 65  LINKAGE

[371]
FROM TRANSMISSION:
112 118877, ON 123 270 29 01
117 031961
118 091349
119 002629 ON 123 270 17 01
120 017271
 001
461 A 115 278 05 17  ROLLER
MOVING

[223]
UP TO TRANSMISSION
112 001686, ON 123 270 11 01
117 001800, ON 123 270 12 01
119 000478, ON 123 270 17 01
[371]
FROM TRANSMISSION:
112 118877, ON 123 270 29 01
117 031961
118 091349
119 002629 ON 123 270 17 01
120 017271
 001
464 A 115 990 21 40  WASHER

[223]
UP TO TRANSMISSION
112 001686, ON 123 270 11 01
117 001800, ON 123 270 12 01
119 000478, ON 123 270 17 01
[371]
FROM TRANSMISSION:
112 118877, ON 123 270 29 01
117 031961
118 091349
119 002629 ON 123 270 17 01
120 017271
 001
465 A 115 278 08 74  PIN 001
466 A 000 981 51 87  NEEDLE 023
467 A 115 278 04 17  ROLLER
FIXED 		001
468 N 006799 008005  LOCK PLATE 001
470 A 115 278 00 62  THRUST WASHER 001
472 A 115 270 04 78  SPRING 001
473 A 115 278 04 40  BRACKET 001
474 N 000137 006204  SPRING WASHER 001
475 N 000933 006102  SCREW

Replaced by: N 304017 006016 		-
475 N 304017 006016  SCREW 001
480 A 115 270 22 74  GOVERNOR

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
484 A 115 272 03 55  SEAL RING 003
484 A 115 272 13 55  SEAL RING 003
485 A 115 270 00 98  FILTER

[235]
UP TO TRANSMISSION:
112 000421, ON 123 270 11 01
117 000751, ON 123 270 12 01
118 007866
119 000212, ON 123 270 17 01
 001
486 A 115 277 08 58  ECCENTRIC RING 001
487 A 115 270 03 42  GEAR 001
488 A 115 993 04 26  DISC SPRING 001
495 A 123 270 17 11  TRANSMISSION CASE 001
----- A 115 991 02 41  FITTING SLEEVE -
----- N 000007 012219  CYLINDRICAL PIN -
----- N 005401 306000  BALL 6 MM

[002]
NO LONGER AVAILABLE INDIVIDUALLY
 -
----- N 005401 308000  BALL 8 MM

[002]
NO LONGER AVAILABLE INDIVIDUALLY
 -
505 A 115 997 01 03  PLUG 001
506 A 115 997 03 03  PLUG

[229]
UP TO TRANSMISSION
112 001886, ON 123 270 11 01
117 001950, ON 123 270 12 01
118 010448
119 000478, ON 123 270 17 01
 001
510 A 115 993 38 03  SPRING 001
511 A 115 277 62 75  PIN 001
512 A 000 981 81 85  BALL 001
513 A 115 997 01 30  SCREW PLUG 001
514 N 007603 010100  SEAL RING/PART NAME MISSING
SEE FIG. NO.:
NOT FOR U.S.A. 569 571 		001
528 N 007603 012104  SEAL RING 001
529 N 007604 012102  SCREW PLUG 001
535 N 007603 008105  SEAL RING 002
536 A 115 997 06 30  SCREW PLUG 002
540 A 114 991 01 29  BALL 10 MM 001
541 A 115 993 13 02  SPRING 001
542 N 007603 018101  SEAL RING 001
543 A 115 997 03 30  SCREW PLUG 001
545 A 115 270 51 32  PISTON
PISTON PUMP

[244]
UP TO TRANSMISSION:
112 007486, ON 123 270 11 01
117 004850, ON 123 270 12 01
118 021372
119 000927, ON 123 270 17 01
 001
547 A 009 997 09 45  SEAL RING 001
548 A 115 277 16 71  SCREW 001
549 N 000137 006204  SPRING WASHER 001
552 N 000625 900201  GROOVED BALL BEARING 001
553 N 000472 062000  LOCK RING

Replaced by: A 003 994 52 41 		-
553 A 003 994 52 41  LOCK 001
554 A 008 997 92 46  SEAL RING

[451]
RANGES OF MAINTENANCE AND DAMAGE IN TRANSPORT
 001
560 A 115 993 34 04  SPRING 001
561 A 115 277 41 31  PISTON 001
562 A 115 277 27 40  BRACKET 001
563 N 007985 005127  SCREW

Replaced by: N 007985 005504 		-
563 N 007985 005504  SCREW 001
564 N 000137 008204  SPRING WASHER 010
566 N 914005 008015  COMBINATION BOLT

Replaced by: N 000933 008150
• N 000137 008204 [1 pcs.] 		-
566 N 000933 008150  SCREW

Replaced by: N 304017 008018 		-
566 N 304017 008018  SCREW 010
569 A 115 277 50 38  PISTON 001
571 A 115 993 05 04  SPRING 001
----- A 115 277 04 32  PISTON
MODULATION PRESSURE REGULATOR VALVE 		001
576 A 115 993 56 03  SPRING

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
584 A 115 270 03 27  SPEEDOMETER DRIVE 001
586 A 115 274 00 60  SEAL RING 001
586 A 007 997 73 46  SEAL RING 001
588 A 115 274 06 28  CASE 001
589 A 005 997 52 45  SEAL RING 001
591 A 115 270 02 72  SCREW
TO PLUG MODULATOR VALVE

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
593 N 007603 016401  SEAL RING
TO PLUG MODULATOR VALVE

[342]
UP TO TRANSMISSION:
117: 030015, EXCEPT FOR: 028451-028465,029866-029915
[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
595 A 115 990 39 01  SCREW 001
596 N 000137 006204  SPRING WASHER 001
598 A 115 993 84 02  SPRING 001
599 A 115 270 06 72  SCREW 001
600 A 006 997 41 45  SEAL RING

Replaced by: A 007 997 14 48 		-
600 A 007 997 14 48  SEAL RING

Replaced by: A 018 997 19 48 		-
600 A 018 997 19 48  SEAL RING 001
605 A 115 262 11 45  FLANGE

Replaced by: A 123 262 04 45
• A 003 997 70 47 [1 pcs.]

[451]
RANGES OF MAINTENANCE AND DAMAGE IN TRANSPORT
 -
605 A 123 262 04 45  FLANGE

Replaced by: A 124 353 07 45 		-
605 A 124 353 07 45  FLANGE

Replaced by: A 124 353 17 45 		-
605 A 124 353 17 45  FLANGE

[455]
CONTAINING ASBESTOS
 001
606 A 123 990 00 60  NUT 001
610 A 116 272 00 76  WASHER 001
615 A 115 270 61 07  VALVE BODY ASSEMBLY 001
618 A 115 277 20 01  VALVE BODY ASSEMBLY
(OIL SEPARATOR PLATE) 		001
620 A 115 277 28 36  VALVE PART 001
621 A 115 993 15 05  SPRING 002
622 A 115 277 26 36  VALVE PART 001
623 A 109 993 17 01  SPRING 001
624 A 115 277 19 14  INTERMEDIATE PLATE 001
626 A 116 277 04 80  GASKET

Replaced by: A 116 277 08 80 		-
626 A 116 277 08 80  GASKET 001
628 A 115 277 23 36  VALVE PART
REVERSE SPEED 		001
630 A 115 277 08 83  LOCKING SHEET 001
631 A 115 277 12 80  GASKET

Replaced by: A 115 277 32 80 		-
631 A 115 277 32 80  GASKET 001
----- N 000084 005131  SCREW 001
633 N 005401 305500  BALL 5.5 MM 002
635 A 115 277 40 29  SHIFT VALVE 001
636 A 116 993 70 01  SPRING 003
640 A 115 270 02 98  FILTER

[346]
FROM TRANSMISSION:
118: 086899, ON 123 270 31 01,123 270 32 01, ALSO INSTALLED ON: 082653-082682,085033-085132
 001
----- A 116 277 01 83  LOCKING SHEET

[002]
NO LONGER AVAILABLE INDIVIDUALLY
 -
----- A 116 277 00 83  LOCKING SHEET

[002]
NO LONGER AVAILABLE INDIVIDUALLY
 -
644 A 115 277 19 40  BRACKET 001
645 N 000084 005131  SCREW 014
646 N 005401 305500  BALL 5.5 MM 007
647 A 116 277 00 75  PIN 001
648 A 116 993 69 01  SPRING
RELAY VALVE B2 		001
650 A 115 270 04 70  REGULATOR VALVE 001
654 A 115 277 25 36  VALVE PART 001
655 A 115 993 28 02  SPRING 001
656 A 115 991 01 60  DOWEL PIN 001
660 A 115 277 20 14  INTERMEDIATE PLATE 001
664 A 115 277 11 83  LOCKING SHEET 001
----- A 115 993 20 02  SPRING 001
665 A 115 277 18 80  GASKET

Replaced by: A 115 277 28 80 		-
665 A 115 277 28 80  GASKET 001
666 N 000084 005131  SCREW 003
668 A 115 277 06 74  PIN 006
669 A 115 277 06 73  LOCK 006
672 N 005401 305500  BALL 5.5 MM

[343]
UP TO TRANSMISSION:
118: 086898, ON 123 270 07 01, EXCEPT FOR: 082653-082682,085033-085132
 001
673 A 115 993 97 03  SPRING 001
674 A 114 991 02 29  BALL 7.0 MM 002
680 N 000931 006191  SCREW
OIL SEPARATION PLATE TO VALVE BODY ASSEMBLY 		010
681 N 000931 006055  SCREW
OIL SEPARATION PLATE TO VALVE BODY ASSEMBLY 		002
682 N 000137 006204  SPRING WASHER
OIL SEPARATION PLATE TO VALVE BODY ASSEMBLY 		012
683 N 900421 006001  THREADED INSERT NB
----- N 900421 005000  THREADED INSERT NB
685 A 115 270 10 68  GUIDE TUBE 002
686 A 115 277 33 50  BUSHING 004
687 A 115 277 28 40  BRACKET/PART NAME MISSING
SEE FIG. NO.: 685H 714 		002
693 N 000933 008116  SCREW

Replaced by: N 000933 008337 		-
693 N 000933 008337  SCREW
VALVE BODY ASSEMBLY TO TRANSMISSION 		011
694 N 000137 008204  SPRING WASHER
VALVE BODY ASSEMBLY TO TRANSMISSION 		011
698 A 115 270 03 98  FILTER

[278]
UP TO TRANSMISSION:112 010486 ON 123 270 11 01
 001
700 N 914026 005110  COMBINATION BOLT
OIL FILTER TO VALVE BODY ASSEMBLY

[278]
UP TO TRANSMISSION:112 010486 ON 123 270 11 01
 002
----- N 000137 005203  SPRING WASHER
OIL FILTER TO VALVE BODY ASSEMBLY

[465]
NO LONGER REQUIRED
 -
----- A 115 270 00 12  OIL PAN

[035]
UP TO CHASSIS:
107: 115.110 409975
108: 115.117 008955
110: 115.017 006304
 001
----- A 115 270 06 12  OIL PAN

[037]
FROM CHASSIS:
107: 115.110 409976
108: 115.117 008956
110: 115.017 006305
 001
706 A 115 271 15 80  GASKET 001
706 A 115 271 16 80  GASKET 001
710 N 000933 008154  SCREW

Replaced by: N 304017 008021 		-
710 N 304017 008021  SCREW 004
712 A 115 271 01 94  SHIM

[279]
FROM TRANSMISSION:112 010487 ON 123 270 11 01
 004
714 A 114 270 00 80  GASKET KIT

Replaced by: A 114 270 32 01 		-
714 A 114 270 32 01  GASKET KIT
VALVE BODY ASSEMBLY 		001
715 A 115 270 03 80  GASKET KIT

Replaced by: A 115 270 23 01 		-
715 A 115 270 23 01  GASKET KIT
TRANSMISSION 		001
747 A 115 270 17 96  LINE
LEFT 		001
750 A 115 270 19 96  LINE
RIGHT 		001
755 A 120 995 00 05  CLAMP
OIL LINES TO ENGINE 		004
756 A 112 997 02 81  GROMMET/PART NAME MISSING
OIL LINES TO ENGINE
NOT FOR U.S.A. 		004
763 A 127 155 01 50  BUSHING
OIL LINES TO ENGINE 		001
765 N 914020 006001  COMBINATION BOLT
OIL LINES TO ENGINE 		003
----- N 000912 006044  SCREW
OIL LINES TO ENGINE

[294]
FROM ENGINE 118:617.912 048619
 001
----- N 007980 006003  LOCK WASHER
OIL LINES TO ENGINE 		001
770 N 915036 008104  HOLLOW SCREW
OIL LINE TO CONVERTER HOUSING 		002
771 N 007603 012104  SEAL RING
OIL LINE TO CONVERTER HOUSING 		004
----- N 914020 006000  COMBINATION BOLT

Replaced by: A 001 990 93 12 		-
----- A 001 990 93 12  SCREW
OIL LINE TO CONVERTER HOUSING 		002
----- A 112 997 02 81  GROMMET
OIL LINE TO CONVERTER HOUSING 		002
----- A 120 995 00 05  CLAMP
OIL LINE TO CONVERTER HOUSING 		002
----- A 115 270 04 84  OIL FILLER PIPE

[050]
UP TO CHASSIS:
107: 115.110 409975
108: 115.117 008955
 001
----- A 115 270 07 84  OIL FILLER PIPE

[051]
FROM CHASSIS:
107: 115.110 409976
108: 115.117 008956
 001
780 A 107 270 00 83  OIL DIPSTICK

Replaced by: A 116 270 00 83 		-
780 A 116 270 00 83  OIL DIPSTICK 001
784 N 007603 014104  SEAL RING
OIL FILLER TO OIL PAN 		002
----- N 915036 010204  HOLLOW SCREW
OIL FILLER TO OIL PAN

[048]
UP TO CHASSIS 110:115.017 006304
[050]
UP TO CHASSIS:
107: 115.110 409975
108: 115.117 008955
 001
----- A 115 990 01 63  HOLLOW SCREW
OIL FILLER TO OIL PAN

[049]
FROM CHASSIS 110:115.017 006305
[051]
FROM CHASSIS:
107: 115.110 409976
108: 115.117 008956
 001
----- N 000125 008418  WASHER
OIL FILLER TO INTAKE MANIFOLD AND TO CAMSHAFT HOUSING 		001
----- N 000933 008154  SCREW

Replaced by: N 304017 008021 		-
----- N 304017 008021  SCREW
OIL FILLER TO INTAKE MANIFOLD AND TO CAMSHAFT HOUSING 		001
----- N 000934 008013  NUT
OIL FILLER TO INTAKE MANIFOLD AND TO CAMSHAFT HOUSING 		001
795 A 015 997 70 82  HOSE

Replaced by: A 019 997 80 82 		-
795 A 019 997 80 82  HOSE
FROM ENGINE JUNCTION TO OIL COOLER 		002
799 A 000 304 00 40  BRACKET
ELECTRIC CABLE TO KICK-DOWN SOLENOID VALVE 		001
----- N 000085 004119  SCREW
ELECTRIC CABLE TO KICK-DOWN SOLENOID VALVE 		001
